Details
Machine
| Teknik Özellik | Değer |
|---|---|
| FUNCTION | Form-Cut-Stack |
| Max. Mould Size | 650 x 435 mm |
| Forming Mould Height (Upper) | 100 mm |
| Forming Mould Height (Lower) | 120 mm |
| Cutting Mould Height (Upper) | |
| Cutting Mould Height (Lower) | |
| Punching Mould Height (Upper) | - |
| Punching Mould Height (Lower) | - |
| Forming, Cutting Area | 630 x 405mm |
| Sheet Width | 710 mm Max. |
| Sheet Thickness | 0,1-1,5 mm Max. |
| Sheet Unwinder Reel | 1300 mm Max. |
| Maximum Sheet Roll Weight | 1500 kg |
| Max. Product Height | Positive 100 mm / Negative 100 mm |
| Max. Dry Cycles | 70 cycles/min. |
| Running Power | 30-50 kW |
| Total Installed Power | 80 kW |
| Vacuum | 105 m3/min |
| Required Compressor | 3 m3/min. |
| Required Chiller | 20.000 Kcal/h. |
| Operation Pressure | 6-8 bar |
| Forming Closing Force | 40.000 daN |
| Cutting Closing Force | 55.000 daN |
| Punching Closing Force | 55.000 daN |
| Pitch Accuracy | 0,15 mm |
| Lubrication System | Automatic machine and chain lubrication |
| Maximum Stacking Height (Sweeper) | 400 mm |
| Maximum Stacking Height (Robot) | 300 mm |
| Approximate Machine Weight (ton) | 3 station – 7,5 t. / 4 station – 8,5 t. |
| Teknik Özellik | Değer |
|---|---|
| FUNCTION | Form-Cut-Stack |
| Max. Mould Size | 700x500mm |
| Forming Mould Height (Upper) | 100 mm max. |
| Forming Mould Height (Lower) | 130 mm max. |
| Cutting Mould Height (Upper) | - |
| Cutting Mould Height (Lower) | - |
| Punching Mould Height (Upper) | - |
| Punching Mould Height (Lower) | - |
| Forming, Cutting Area | 650x450 mm |
| Sheet Width | 740 mm Max |
| Sheet Thickness | 0,1-2 mm Max. |
| Sheet Unwinder Reel | 1300 mm Max. |
| Maximum Sheet Roll Weight | 1500 kg |
| Max. Product Height | Positive 100 mm / Negative 100 mm |
| Max. Dry Cycles | 70 cycles/min. |
| Running Power | 30-50 kW |
| Total Installed Power | 150 kVA / 160 kVA - Foam |
| Vacuum | 105 m³/min |
| Required Compressor | 3 m³/min. |
| Required Chiller | 20.000 Kcal/h. |
| Operation Pressure | 6-8 bar |
| Forming Closing Force | 70.000 daN |
| Cutting Closing Force | 70.000 daN |
| Punching Closing Force | 70.000 daN |
| Pitch Accuracy | 0,15 mm |
| Lubrication System | Automatic machine and chain lubrication |
| Maximum Stacking Height (Sweeper) | 400 mm |
| Maximum Stacking Height (Robot) | 300 mm |
| Approximate Machine Weight (ton) | 3 station - 12 t. / 4 station - 16 t. |
| Teknik Özellik | Değer |
|---|---|
| FUNCTION | Form-Cut-Stack |
| Max. Mould Size | 700 x 585 mm |
| Forming Mould Height (Upper) | 125 - 175 mm (with adaptor) 305 - 355 mm (without adaptor) |
| Forming Mould Height (Lower) | 125 - 175 mm |
| Cutting Mould Height (Upper) | 30 - 140 mm |
| Cutting Mould Height (Lower) | 140 mm fix |
| Punching Mould Height (Upper) | - |
| Punching Mould Height (Lower) | 95 - 205 mm |
| Forming, Cutting Area | 650 x 450 mm |
| Sheet Width | 740 mm Max |
| Sheet Thickness | 0,2-2 mm Max. |
| Sheet Unwinder Reel | 1300 mm Max. |
| Maximum Sheet Roll Weight | 1500 kg |
| Max. Product Height | Positive 100 mm / Negative 100 mm |
| Max. Dry Cycles | 70 cycles/min. |
| Running Power | 30-50 kW |
| Total Installed Power | 150 kVA / 160 kVA - Foam |
| Vacuum | 105 m³/min |
| Required Compressor | 3 m³/min. |
| Required Chiller | 20.000 Kcal/h. |
| Operation Pressure | 6-8 bar |
| Forming Closing Force | 70.000 daN |
| Cutting Closing Force | 70.000 daN |
| Punching Closing Force | 70.000 daN |
| Pitch Accuracy | 0,15 mm |
| Lubrication System | Automatic machine and chain lubrication |
| Maximum Stacking Height (Sweeper) | 400 mm |
| Maximum Stacking Height (Robot) | 300 mm |
| Approximate Machine Weight (ton) | 3 station - 12 t. / 4 station - 16 t. |
| Teknik Özellik | Değer |
|---|---|
| FUNCTION | Form-Punch-Cut-Stack |
| Max. Mould Size | 700 x 585 mm |
| Forming Mould Height (Upper) | 125 - 175 mm (with adaptor) 305 - 355 mm (without adaptor) |
| Forming Mould Height (Lower) | 125 - 175 mm |
| Cutting Mould Height (Upper) | 30 - 140 mm |
| Cutting Mould Height (Lower) | 180 mm fix. |
| Punching Mould Height (Upper) | - |
| Punching Mould Height (Lower) | 95 - 205 mm |
| Forming, Cutting Area | 650 x 450 mm |
| Sheet Width | 740 mm Max. |
| Sheet Thickness | 0,1-2 mm Max. |
| Sheet Unwinder Reel | 1300 mm Max. |
| Maximum Sheet Roll Weight | 1500 kg |
| Max. Product Height | Positive 100 mm / Negative 100 mm |
| Max. Dry Cycles | 70 cycles/min. |
| Running Power | 30-50 kW |
| Total Installed Power | 150 kVA / 160 kVA - Foam |
| Vacuum | 105 m³/min |
| Required Compressor | 3 m³/min. |
| Required Chiller | 20.000 Kcal/h. |
| Operation Pressure | 6-8 bar |
| Forming Closing Force | 70.000 daN |
| Cutting Closing Force | 70.000 daN |
| Punching Closing Force | 70.000 daN |
| Pitch Accuracy | 0,15 mm |
| Lubrication System | Automatic machine and chain lubrication |
| Maximum Stacking Height (Sweeper) | 400 mm |
| Maximum Stacking Height (Robot) | 300 mm |
| Approximate Machine Weight (ton) | 3 station - 12 t. / 4 station - 16 t. |
| Teknik Özellik | Değer |
|---|---|
| FUNCTION | Form-Cut-Stack |
| Max. Mould Size | 800 x 580 mm |
| Forming Mould Height (Upper) | 150 - 330 mm |
| Forming Mould Height (Lower) | 150 - 250 mm |
| Cutting Mould Height (Upper) | 50 - 150 mm |
| Cutting Mould Height (Lower) | 150 mm fix |
| Punching Mould Height (Upper) | - |
| Punching Mould Height (Lower) | - |
| Forming, Cutting Area | 750 x 530 mm |
| Sheet Width | 845 mm Max. |
| Sheet Thickness | 0,1-2 mm Max. |
| Sheet Unwinder Reel | 1200 mm Max. |
| Maximum Sheet Roll Weight | 1500 kg |
| Max. Product Height | Positive 130 mm / Negative 130 mm |
| Max. Dry Cycles | 70 cycles/min. |
| Running Power | 30-50 kW |
| Total Installed Power | 190-200 kVA/305-315 kVA - Foam |
| Vacuum | 200 m3/min. |
| Required Compressor | 5 m3/min. |
| Required Chiller | 40.000 Kcal/h. |
| Operation Pressure | 6-8 bar |
| Forming Closing Force | 80.000 daN |
| Cutting Closing Force | 80.000 daN |
| Punching Closing Force | 80.000 daN |
| Pitch Accuracy | 0,15 mm |
| Lubrication System | Automatic machine and chain lubrication |
| Maximum Stacking Height (Sweeper) | 400 mm |
| Maximum Stacking Height (Robot) | 500 mm |
| Approximate Machine Weight (ton) | 3 station - 18 t. / 4 station - 23 t. |
| Teknik Özellik | Değer |
|---|---|
| FUNCTION | Form-Punch-Cut-Stack |
| Max. Mould Size | 800 x 580 mm |
| Forming Mould Height (Upper) | 150 - 330 mm |
| Forming Mould Height (Lower) | 150 - 250 mm |
| Cutting Mould Height (Upper) | 50 - 150 mm |
| Cutting Mould Height (Lower) | 150 mm fix |
| Punching Mould Height (Upper) | 145 - 325 mm |
| Punching Mould Height (Lower) | 250 mm fix. |
| Forming, Cutting Area | 750 x 530 mm |
| Sheet Width | 845 mm Max. |
| Sheet Thickness | 0,1-2 mm Max. |
| Sheet Unwinder Reel | 1200 mm Max. |
| Maximum Sheet Roll Weight | 1500 kg |
| Max. Product Height | Positive 130 mm / Negative 130 mm |
| Max. Dry Cycles | 70 cycles/min. |
| Running Power | 30-50 kW |
| Total Installed Power | 190-200 kVA/305-315 kVA - Foam |
| Vacuum | 200 m3/min. |
| Required Compressor | 5 m3/min. |
| Required Chiller | 40.000 Kcal/h. |
| Operation Pressure | 6-8 bar |
| Forming Closing Force | 80.000 daN |
| Cutting Closing Force | 80.000 daN |
| Punching Closing Force | 80.000 daN |
| Pitch Accuracy | 0,15 mm |
| Lubrication System | Automatic machine and chain lubrication |
| Maximum Stacking Height (Sweeper) | 400 mm |
| Maximum Stacking Height (Robot) | 500 mm |
| Approximate Machine Weight (ton) | 3 station - 18 t. / 4 station - 23 t. |
| Teknik Özellik | Değer |
|---|---|
| FUNCTION | Form-Cut-Stack |
| Max. Mould Size | 920 x 720 mm |
| Forming Mould Height (Upper) | 150 - 240 mm (with adaptor) 360 - 450 mm (without adaptor) |
| Forming Mould Height (Lower) | 150 - 240 mm |
| Cutting Mould Height (Upper) | 40 - 190 mm |
| Cutting Mould Height (Lower) | 190 mm fix |
| Punching Mould Height (Upper) | - |
| Punching Mould Height (Lower) | - |
| Forming, Cutting Area | 870 x 670 mm |
| Sheet Width | 960 mm Max. |
| Sheet Thickness | 0,1-2 mm Max. |
| Sheet Unwinder Reel | 1300 mm Max. |
| Maximum Sheet Roll Weight | 1500 kg |
| Max. Product Height | Positive 150 mm / Negative 150 mm |
| Max. Dry Cycles | 70 cycles/min. |
| Running Power | 100-130 kW |
| Total Installed Power | 230-240 kVA/315-325 kVA - Foam |
| Vacuum | 200 m3/min. |
| Required Compressor | 5 m3/min. |
| Required Chiller | 40.000 Kcal/h. |
| Operation Pressure | 6-8 bar |
| Forming Closing Force | 90.000 daN |
| Cutting Closing Force | 90.000 daN |
| Punching Closing Force | 90.000 daN |
| Pitch Accuracy | 0,15 mm |
| Lubrication System | Automatic machine and chain lubrication |
| Maximum Stacking Height (Sweeper) | 500 mm |
| Maximum Stacking Height (Robot) | 500 mm |
| Approximate Machine Weight (ton) | 3 station - 21 t. / 4 station - 28 t. |
| Teknik Özellik | Değer |
|---|---|
| FUNCTION | Form-Punch-Cut-Stack |
| Max. Mould Size | 920 x 720 mm |
| Forming Mould Height (Upper) | 150 - 240 mm (with adaptor) 360 - 450 mm (without adaptor) |
| Forming Mould Height (Lower) | 150 - 240 mm |
| Cutting Mould Height (Upper) | 40 - 190 mm |
| Cutting Mould Height (Lower) | 190 mm fix |
| Punching Mould Height (Upper) | 175 - 325 mm |
| Punching Mould Height (Lower) | 260 mm fix |
| Forming, Cutting Area | 870 x 670 mm |
| Sheet Width | 960 mm Max. |
| Sheet Thickness | 0,1-2 mm Max. |
| Sheet Unwinder Reel | 1300 mm Max. |
| Maximum Sheet Roll Weight | 1500 kg |
| Max. Product Height | Positive 150 mm / Negative 150 mm |
| Max. Dry Cycles | 70 cycles/min. |
| Running Power | 100-130 kW |
| Total Installed Power | 230-240 kVA/315-325 kVA - Foam |
| Vacuum | 200 m3/min. |
| Required Compressor | 5 m3/min. |
| Required Chiller | 40.000 Kcal/h. |
| Operation Pressure | 6-8 bar |
| Forming Closing Force | 90.000 daN |
| Cutting Closing Force | 90.000 daN |
| Punching Closing Force | 90.000 daN |
| Pitch Accuracy | 0,15 mm |
| Lubrication System | Automatic machine and chain lubrication |
| Maximum Stacking Height (Sweeper) | 500 mm |
| Maximum Stacking Height (Robot) | 500 mm |
| Approximate Machine Weight (ton) | 3 station - 21 t. / 4 station - 28 t. |
